General
3.2

Survey and construction

Bolt for eyelet
Upper part
Telescope-tube
Handle to control the
FTZ-UNI-15
Spring bolt to adjust the
gripping range
Fixingholes for vertically adjustable
rubberplate (special accessories)
Gripping arm
Rectangle tube for
gripping range
Rubber gripper
Gripper lengh
3.3

Technical data

The exact technical data (carrying capacity / working load limit (WLL), dead weight, etc.) are listed on the type plate.
53100256
Opening range
10 / 21
Automatic release to adjust
fullautomatically gripping and
opening
Handle to control the
FTZ-UNI-15
Gripping arm
Depth
