Material diagram
Connection Diagram
We'll keep the connection from our previous lesson regarding the IR receiver but this time we connect the LED as
well.
The LED have 2 pins, long pin and short pin. The long pin is the positive that we connect directly to GPIO27 and the
short pin goes through the resistor to the GND connection on the raspberry pi.
Material Name
IR Remote
IR Receiver
LED
220/330ohm resistor
Raspberry Pi Board
T-Cubbler Plus
40P GPIO Cable
Breadboard
Jumper wires
99 of 114
Number (amount)
1
1
1
1
1
1
1
1
Several
