Luminous Intensity: 12000-14000mcd
Pin definition
Hardware required
Below is the hardware we'll need to complete this lesson.
Please note the 220/330ohm resistor, we will need 3 of them.
any, either 220 or 330 will work, we can also combine few 220 and few 330ohm resistors, there is no problem with
that.
Material diagram
Material Name
RGB LED
220/330Ω resistor
Raspberry Pi Board
T-Cubbler Plus
40P GPIO Cable
Breadboard
30 of 114
Number (amount)
1
3
1
1
1
1
