As we can see, the segment LED is marked with letters in this pin definition, the real segment in the kit doesn't have
any letters on it. Please refer to this definition while wiring the segment LED to make sure we wire it correctly.
Hardware required
Below is the hardware we'll require for this lesson, 1 digit (don't confused with 4 digit) segment display and 220 or
330 ohm resistors, we'll need 8 of them.
Material diagram
Material Name
1 Digit 7 Segment display
220/330Ω Resistors
Raspberry Pi Board
T-Cubbler Plus
40P GPIO Cable
Breadboard
Jumper wires
34 of 114
Number (amount)
1
8
1
1
1
1
Several
