Connection Diagram
Red wire for 5V positive black is for the negative, the orange wire which we'll use for PWN commands will be
connected directly to GPIO18.
Connection
Servo
Yellow wire
Red wire
Black wire
Raspberry Pi
GPIO18
5V
GND
50 of 114
