Application effect
Running the script will turn on red LED, green LED and then blue LED with a space of 0.3 seconds between each turn
on and turn off.
LESSON 8: 1 DIGIT 7 SEGMENT DISPLAY
Introduction
In this lesson we'll learn about the segment display. In our kit we have 2 types of segment display one is single (1
digit) segment display and one is 4 digit. both displays are the same the only difference is the amount of digits we
control. In our first lesson we will learn how to control one segment and show a number.
A segment can show a number between 0 and 9.
Pin Definition
33 of 114
