Hardware required
The main component in this lesson is the thermistor sensor, it looks like LED with a small black pin at the end of it.
We'll also need the 10K ohm resistor from the previous lessons to connect to the thermistor and GND pin.
Please make sure not to confuse 10K ohm resistor with 10 ohm resistor.
And off course, our buddy the PCF8591 that we used and will use in this lesson to get the value from the thermistor
sensor.
Material diagram
Material Name
Thermistor sensor
10KΩ resistor
PCF8591
Raspberry Pi Board
T-Cubbler Plus
40P GPIO Cable
Breadboard
Jumper wires
78 of 114
Number (amount)
1
1
1
1
1
1
1
Several
