Material diagram
Connection Diagram
In the connection diagram we can see that we are going to connect the RGB LED just as we did in previous lessons to
GPIO17,27 and 22.
The touch sensor have 3 different pins, one is the positive (VCC) another is negative (GND) and GPIO pin that we will
configure as GPIO.IN to receive a finger touch over the sensor.
Material Name
40P GPIO Cable
Breadboard
Jumper wires
62 of 114
Number (amount)
1
1
Several
