Hardware required
We'll need a 220/330ohm resistor (8 of them, 1 for each pin) for this example.
Please note you can use either 220 or 330 or combine both of them, all options will work perfectly fine.
Material diagram
Material Name
Segment Display
220/330Ω Resistors
Raspberry Pi Board
T-Cubbler Plus
40P GPIO Cable
Breadboard
Jumper wires
39 of 114
Number (amount)
1
8
1
1
1
1
Several
