Connection Diagram
as we can see in the diagram, the connection is pretty simple. we connect the positive pin of the buzzer into GPIO17
on the raspberry pi and the negative pin to the ground.
Connection
Please note: the long pin of the buzzer is the positive pin while the short pin of the buzzer is the negative pin.
Active buzzer
Long Pin (+)
Short Pin (-)
Raspberry Pi
GPIO17
GND
