Material diagram
Connection Diagram
The diagram is very similar to the previous we've made. Let's take a look over the photo resistance pins, it doesn't
have a short or long one.
We'll need to connect one pin to the 10K ohm resistor and then to the GND as well as to the AINT0 pin on the
PCF8591 module. The other pin, the positive side we choose goes directly to 5V.
The PCF8591 module connections stays exactly the same.
Material Name
40P GPIO Cable
Breadboard
Jumper wires
74 of 114
Number (amount)
1
1
Several
