Connection Diagram
The diagram stays the same as previous lessons except we don't connect the resistor right now as we have no use in
it for the potentiometer.
The potentiometer have 3 pins, GND, VCC and AINT0 make sure to connect the correct pins to the right places.
Connection
Component
Up Pin
Mid Pin
Raspberry Pi
5V
AINT0
