Chapter 8 Upgrade the firmware

8.1 Matters Needing Attention

Before the upgrade, check the mainboard information of the device before uploading the
upgrade file. Do not change the name of the upgrade file. If not, contact support engineers
for confirmation.
8.2 Check and Upgrade the
Mainboard
Step 1: Open
Step 2: Check the motherboard information
Input - Advanced Settings - System Info (Motherboard)
Output - Advanced Settings - System (Motherboard)
Step 3: Select multiple nodes that have been checked on the mainboard
Step 4: Firmware Upgrade - Select files
Upgrade sequence: public-> Output ->input
Step 5: Click Upload.
Do not lose power during the upload process.
Step 6: Restart the node
