RGBlink IC2+ User Manual page 40

5.7.1 Page Adjustment Button Settings
Click the button and select the corresponding page on the right of the page button in
Configuration - Basic Properties.
5.7.2 Button to Send UDP Command Settings
To select the page where you can add or modify commands based on existing buttons, click on
the right side of Configuration-Command... . Popover dialog box to modify. If TCP is not
selected, the client sends commands using UDP. If HEX is not selected, the command is the
ACSII code. You need to set the destination IP address and port number. The button supports
16 commands, and the interval for each command must be longer than 50ms.Command area
Enter a command that contains a maximum of 128 characters.
35
