RGBlink IC2+ User Manual page 47

No. Name
The default
configuration
4
Pre-scheduled
release
5
refresh
6
Clear the screen
7
Signal grouping
8
Signal source
preview
window
9
Audio switching
wall
10
Return home
button
11
Environmental
control
12
Function
buttons
13
Click Take Effect to make the preset arrangement

window of the client, and the real-time window
opening of other clients of the current video wall
will not be updated at this time. The operation on
the local client is temporarily performed on the
client. Click on the pre-arranged release will
proceed to the wall operation.
After clicking, the window opening condition of the

preset arrangement of the current client's video
wall will be published to the actual video wall.
Refresh the current video wall window opening

information to the local client.
After clicking, the window of the current video wall

will be opened to clear.
Displays the signal group name to which this

signal component is bound
previews the signals of all input nodes

previews a signal that passes the IPC forwarding

node
No preview signal, show no blueprint.

Pull the signal to this window for independent

audio switching
Click to return to the home page, and then jump to

other areas or screen operation pages from the
home page.
Click to enter the customized environment

operation interface, including power timing device,
camera, large-screen switch, light, air conditioner,
etc.
log out, minimize, and close

42
Description
