Spectralink DECT Server 2500 Installation Guide
Figure 4 Media Resource Card Connection

General Installation Information

General Mounting Safety Precautions
Important
Electrical shock hazards from the telecommunication network and AC mains
are possible with this equipment. To minimize risk to service personnel and
users, the system must be connected to an outlet with a third-wire earth
connection.
• Keep the area around the Spectralink DECT Server 2500 clean and free of clutter.
• Decide on a suitable surface that will hold the Spectralink DECT Server 2500 unit. It should be
situated in a clean, dry, and dust-free area that is well ventilated. Avoid areas where heat,
electrical noise, and electromagnetic fields are generated.
• Place it near an earthed power outlet.

Installing the Spectralink DECT Server 2500 on a Flat Surface

Before you start installation, take notice of the following safety precautions.
• Ensure the surface can support the weight of the unit.
• Never install the Spectralink DECT Server 2500 on the floor.
• Never place anything on top of the Spectralink DECT Server 2500. The top plate must be free
to allow sufficient cooling.
To Install the Spectralink DECT Server 2500 on a Flat Surface
1 Remove the Spectralink DECT Server 2500 from its package.
2 Before placing the unit, carefully turn it upside down and mount the four rubber pads supplied
in the package. One must be placed at each corner of the bottom plate.
3 Place it on a clean, flat, horizontal surface.
14205700 Version 9.0
June, 2015
A Ethernet
7
