Spectralink DECT Server 2500 Installation Guide
Connections
Figure 1
CPU Card Connections
Note
Link connections must not be left open. You have to either plug in a link cable
or a terminator connector for protection and for stable functionality.
Figure 2
RJ45 Connections for Base Stations
Figure 3
RJ45 Connections for AB Lines
14205700 Version 9.0
June, 2015
Link upwards
Link downwards
USB
Ethernet
A: RJ45 Connection
B: RJ45 Connection
A RJ45 Connection
B RJ45 Connection
C RJ45 Connection
D RJ45 Connection
RS232
6
