EVAL-M7-HVMOS-INV user guide
Evaluation power board with M7 connector
System design
S. No. Ref Designator
50 R38
51 R40
52 R41
53 R42
54 R43
55 R44
56 R45
57 R46
58 RS1
59 RS2, RS3
60 RS4, RS5
61 RT1
62 RT2
63 TP1, TP2, TP3,
TP4
64 U2
User guide
Description
RES / STD / 62k / 100mW / 1% /
100ppm/K / -55℃ to 155℃ / 0603 /
SMD / -
RES / STD / 1.5k / 100mW / 1% /
100ppm/K / -55℃ to 155℃ / 0603 /
SMD / -
RES / STD / 48.7k / 100mW / 1% /
100ppm/K / -55℃ to 155℃ / 0603 /
SMD / -
RES / STD / 22k / 100mW / 1% /
100ppm/K / -55℃ to 155℃ / 0603 /
SMD / -
RES / STD / 510k / 100mW / 1% /
100ppm/K / -55℃ to 155℃ / 0603 /
SMD / -
RES / STD / 820R / 100mW / 1% /
100ppm/K / -55℃ to 155℃ / 0603 /
SMD / -
RES / STD / 4.7R / 250mW / 1% /
100ppm/K / -55℃ to 155℃ / 1206 /
SMD / -
RES / STD / 9.76k / 100mW / 1% /
100ppm/K / -55℃ to 155℃ / 0603 /
SMD / -
RES / STD / 75mR / 3W / 1% / 50ppm/K /
-55℃ to 170℃ / 2512 / SMD / -
RES / STD / 75mR / 3W / 1% / 50ppm/K /
-55℃ to 170℃ / 2512 / SMD / -
RES / STD / 5.1R / 250mW / 1% /
100ppm/K / -55℃ to 155℃ / 1206 /
SMD / -
RES / NTC / 10R / 1.8W / 20% / - / -55℃
to 170℃ / 5.25mm C X 0.60mm W
9.50mm L X 4.5mm T X 14mm H / - / -
RES / NTC / 47k / 500mW / - / - / -40℃
to 125℃ / 2.54mm C X 0.60mm W
3.30mm L X 3.00mm T X 9.00mm H /
THT / -，3%
Test Point THT, Black
Wide Input Range Low Noise 300mA 5V
LDO
Manufacturer
Vishay
Yageo
Vishay
Vishay
Vishay
Vishay
Vishay
Vishay
Bourns
Bourns
Vishay
TDK
Corporation
Vishay
Keystone
Electronics
Corp.
Infineon
Technologies
24 of 30
Manufacturer P/N
CRCW060362K0FK
RC0603FR-071K5L
CRCW060348K7FK
CRCW060322K0FK
CRCW0603510KFK
CRCW0603820RFK
CRCW12064R70FK
CRCW06039K76FK
CRA2512-FZ-R075ELF
CRA2512-FZ-R075ELF
CRCW12065R10FK
B57235S0100M000
NTCLE100E3473HB0
5001
IFX54441EJ V50
Revision 1.0
2021-06-28
