EVAL-M7-HVMOS-INV user guide
Evaluation power board with M7 connector
System design
S. No. Ref Designator
20 C2, C6, C7,
C8,C9, C10, C32
21 ZD2
22 C33
23 C35, C37
24 C38
25 CY1, CY2
26 D1
27 D2
28 D3, D4, D5, D6,
D7, D8
29 D9
30 D10
31 F1
32 J3
33 L1
User guide
Description
7.00mm L X 7.00mm T X 10.00mm H /
THT / -
CAP / CERA / 1nF / 50V / 1% / C0G (EIA) /
NP0 / -55℃ to 125℃ / 0603(1608) /
SMD / -, CAP / CERA / 1nF / 16V / 10% /
X7R (EIA) / -55℃ to 125℃ / 0603(1608)
/ SMD / -
Zener Diode with Surge Current
Specification
CAP / CERA / 220nF / 25V / 10% / X5R
(EIA) / -55℃ to 85℃ / 0603(1608) /
SMD / -
CAP / CERA / 1nF / 25V / 5% / C0G (EIA) /
NP0 / -55℃ to 125℃ / 0603(1608) /
SMD / -, CAP / CERA / 1nF / 25V / 5% /
C0G (EIA) / NP0 / -55℃ to 125℃ /
0603(1608) / SMD / -
CAP / CERA / 2.2nF / 50V / 10% / X5R
(EIA) / -55℃ to 85℃ / 0603(1608) /
SMD / -
CAP / CERA / 2.2nF / 1kV / 20% / Y5U
(EIA) / -40℃ to 125℃ / 7.50mm C X
0.60mm W 9.00mm L X 5.00mm T X
13.00mm H / - / -
High Voltage Surface-Mount Schottky
Rectifier, VRRM 100V
Surface Mount Ultrafast Rectifier
1.0A/1000V
Surface Mount Fast Switching Diode
Surface-Mount Schottky Barrier
Rectifier, VRRM 45V
Super Fast Recovery Diode, VR 200 V, IF
1 A
RES / STD / - / - / - / - / -55℃ to 125℃ /
5.08mm C X 0.60mm W 8.50mm L X
4.00mm T X 7.90mm H / - / -
The part can be named as M7-38-F,
Connector, 38 pins, 2.54 mm pitch,
Board to Board, Right Angle
IND / STD / 5mH / 2.5A / 30% / -40℃ to
125℃ / 95mR / THT / Inductor, THT, 4
Manufacturer
Kemet
Vishay
MuRata
MuRata
MuRata
Vishay
Vishay
Vishay
Diodes
Incorporated
Vishay
ROHM
Semiconductor
s
Hollyland
(China)
Electronics
Technology
Corp.,Ltd
Sullins
Wurth
Elektronik
22 of 30
Manufacturer P/N
C0603C102F5GAC,
C0603C102K4RACTU
BZD27C22P-HE3-08
GRM188R61E224KA88
GRM1885C1E102JA01
GRM188R61H222KA01
VY2222M35Y5US6TL7
SS2H10-E3/52T
US1M-E3/61T
1N4148W-13-F
BYS10-45-E3/TR3
RF071MM2STR
5EF-040H
PPTC192LJBN-RC
7.45E+08
Revision 1.0
2021-06-28
