EVAL-M7-HVMOS-INV user guide
Evaluation power board with M7 connector
System design
S. No. Ref Designator
5 E1, E2
6 J1, J2
7 CX1, CX2
8 BR1
9 C1, C22
10 C3
11 C4
12 C5
13 C13, C21
14 C24
15 C26
16 C27
17 C29
18 C30
19 C31
User guide
Description
CAP / ELCO / 82 uF / 450 V / 20% / - / -
25℃ to 105℃ /
Horizontal Cable Entry With Rising
Cage Clamp - WR-TBL, 3Pins
CAP / FILM / 470nF / 630V / 10% / MKP
(Metallized Polypropylene)
4 Amp Single Phase Glass Passivated
Bridge Rectifier, 600V
CAP / CERA / 100nF / 50V / 10% / X7R
(EIA) / -55℃ to 125℃ / 603(1608) /
SMD / -
CAP / CERA / 10nF / 50V / 10% / X7R
(EIA) / -55℃ to 125℃ / 0603 / SMD / -
CAP / ELCO / 100uF / 16V / 20% /
Aluminiumelectrolytic / -40℃ to 85℃
/ 2.00mm C X 0.50mm W 5.00mm Dia X
12.50mm H / THT / -
CAP / FILM / 330nF / 400V / 5% / - / -40
℃ to 105℃ / 15.00mm C X 0.80mm W
18.00mm L X 7.00mm T X 14.00mm H /
THT / -
CAP / ELCO / 330uF / 25V / 20% /
Aluminiumelectrolytic / -40℃ to 85℃
/ 3.50mm C X 0.60mm W 8.00mm Dia X
13.00mm H / THT / -
CAP / CERA / 100nF / 630V / 10% / X7R
(EIA) / -55℃ to 125℃ / 1812 / SMD / -
CAP / CERA / 1nF / 630V / 10% / X7R
(EIA) / -55℃ to 125℃ / 1206(3216) /
SMD / -
CAP / ELCO / 220uF / 16V / 20% /
Aluminiumelectrolytic / -40℃ to 85℃
/ 2.50mm C X 0.50mm W 6.30mm Dia X
12.50mm H / THT / -
CAP / CERA / 10uF / 16V / 10% / X5R
(EIA) / -55℃ to 85℃ / 0805(2012) /
SMD / -
CAP / ELCO / 100uF / 35V / 20% /
Aluminiumelectrolytic / -40℃ to 85℃
/ 2.50mm C X 0.50mm W 6.30mm Dia X
12.50mm H / - / -
CAP / CERA / 1nF / / 20% / E (JIS) / -40
℃ to 125℃ / 7.50mm C X 0.60mm W
Manufacturer
Wurth
Elektronik
Wurth
Elektronik
Wurth
Elektronik
Micro
Commercial
Components
AVX
AVX
Wurth
Elektronik
Wurth
Elektronik
Wurth
Elektronik
Wurth
Elektronik
MuRata
Wurth
Elektronik
MuRata
Wurth
Elektronik
MuRata
21 of 30
Manufacturer P/N
861021483005
691216510003S
890324025039CS
GBU4J-BP
06035C104K4Z2A
06035C103K4Z2A
'860010473007
890283325008CS
'860010474012
8.85E+11
GRM31BR72J102KW01
'860010373010
GRM219R61C106KA73
'860010573007
DE6E3KJ102MN3A
