EVAL-M7-HVMOS-INV user guide
Evaluation power board with M7 connector
System design
S. No. Ref Designator
34 L2
35 LED1
36 MP1
37 R1, R34, R36
38 R3, R6
39 R5, R12, R14,
R16, R21, R23,
R25
40 R7
41 R8, R9, R10, R17,
R18, R19
42 R11, R13, R15,
R20, R22, R24
43 R31
44 R39
45 R26
46 R27, R28
47 R29, R30
48 R32, R35, R37
49 R33
User guide
Description
pin, 13.80 mm L X 23.00 mm W X 25.50
mm H body / THT / -
IND / STD / 2.2uH / 2.5A / 20% / -40℃
to 125℃ / 71mR / SMD / Inductor, SMD;
2-Leads, 4.50 mm L X 4 mm W X 3.50
mm H body / SMD / -
LED 3mm Red Through Hole Lamp
Customized Heat sink - 4 pins
RES / STD / 3MEG / 250mW / 1% /
100ppm/K / -55℃ to 155℃ / 1206 /
SMD / -
RES / STD / 1MEG / 250mW / 1% /
100ppm/K / -55℃ to 155℃ / 1206 /
SMD / -
RES / STD / 10k / 100mW / 1% /
100ppm/K / -55℃ to 155℃ / 0603 /
SMD / -
RES / STD / 20k / 125mW / 1% /
100ppm/K / -55℃ to 155℃ / 0805 /
SMD / -
RES / STD / 0R / - / 0R / - / -55℃ to 155
℃ / 0603 / SMD / -
RES / STD / 470R / 100mW / 1% /
100ppm/K / -55℃ to 155℃ / 0603 /
SMD / -
RES / STD / 0R / 125mW / 0R / 0ppm/K /
-55℃ to 155℃ / 0805 / SMD / -
RES / STD / 0R / 100mW / 0R / 0ppm/K /
-55℃ to 155℃ / 0603 / SMD / -
RES / STD / 0R / 125mW / 0R / 0ppm/K /
-55℃ to 155℃ / 0805 / SMD / -
RES / - / 0R / 500mW / - / - / - / 0612 /
SMD / -
RES / STD / 0R / 100mW / 0R / 0ppm/K /
-55℃ to 155℃ / 0603 / SMD / -
RES / STD / 15MEG / 250mW / 5% /
200ppm/K / -55℃ to 155℃ / 1206 /
SMD / -
RES / STD / 68k / 250mW / 1% /
100ppm/K / -55℃ to 155℃ / 1206 /
SMD / -
Manufacturer
Wurth
Elektronik
LiteOn
Optoelectronics
Infineon
Technologies
Vishay
Vishay
Yageo
Vishay
Vishay
Vishay
Yageo
Yageo
Yageo
Vishay
Yageo
Yageo
Vishay
23 of 30
Manufacturer P/N
7.45E+08
LTL-1CHEE
HS-55-55-25
CRCW12063M00FK
CRCW12061M00FK
RC0603FR-0710KL
CRCW080520K0FK
CRCW06030000Z0
CRCW0603470RFK
RC0805JR-070RL
RC0603JR-070RL
RC0805JR-070RL
RCL06120000Z0EA
RC0603JR-070RL
RC1206JR-0715ML
CRCW120668K0FK
