Creality Laser Module Quick Start Manual page 19

开始
Start
断开电源
Disconnect the power
拔出X\Y电机线及限位开关线
Pull out the X\Y motor
wire and limit switch wire
连接控制盒和打印机
Connect the control
box to the printer
安装激光模组固定板
Install the laser
module fixing plate
安装激光模组
Install the laser module
插入激光模组线
Plug Laser Module wire
放置金属保护板及雕刻材料
Placing metal protective plates
and engraving materials
调整激光模组焦距
Adjust focus of laser module
修改GRBL配置参数并重启控制盒
Modify the GRBL configuration
parameters and restart the
control box
准备雕刻文件并存入TF卡
Prepare engraving file
and save it to TF card
将TF卡插入控制盒卡槽
Insert the TF card into the
card slot of the control box
接通电源并打开开关
Power on and turn
on the switch
等待初始化完成
Wait for initialization
completion
按下微动开关进入预览模式
Press the micro switch
to enter preview mode
再次按下微动开关进行雕刻
Press the micro switch
again to engrave
是否按下微动开关
Press microswitch,
Yes or No
短按/Short Press
是否处于暂停模式
In pausing mode,
Yes or No
是/YES
继续雕刻
Resume engraving
长按/Long Press
否/NO
暂停雕刻
Pause engraving
结束
End
离线工作
Offline operation
停止雕刻
Stop engraving
