Summary of Contents for Creality K1C
- Page 1 Create reality，achieve dreams 3D Printer User Manual V1.0...
- Page 2 Users should comply with the laws and regulations of the corresponding countries and regions where the equipment is located (used), abide by professional ethics, pay attention to safety obligations, and strictly prohibit the use of our products or equipment for any illegal purposes; Creality will not be responsible for any violators' legal liability under any circumstance;...
-
Page 3: Table Of Contents
12-12 ......................................................13-17 4 First Printing 4.1 USB flash disk Printing ....................................................13-13 ........................................................4.2 LAN Printing 14-15 ....................................................4.3 Creality Cloud Printing 16-17 5. Functional Specification ..................................................18-21 5.1 Extrude、Filament Retreat ..................................................18-18 ........................................................5.2 AI camera 19-21 ............................................... -
Page 4: About The Device
1. About the Device 1.1 About the Printer Top cover Air filter element Nozzle assembly assembly camera Filament detection Side Fan Front door Printing platform Material barrel Power outlet Touch screen Switch USB flash disk port Toggle Switch 01 01... -
Page 5: Device Specifications
Sprite Direct Drive Extruder Supported Filament PLA/TPU/PETG/ASA/ABS/PET/Carbon/PLA-CF/PA-CF Max. Heated Bed Temperature 100℃ 300℃ Max. Nozzle Temperature User Interface 4.3 inch touch screen USB Flash Disk/LAN Printing/Creality Cloud Printing Print lnterface Power Loss Recovery Filament Detection Auto leveling camera 01 02... -
Page 6: Packing List
After-Sales Service Card assembly ×1 Card ×1 ×1 assembly ×1 DE FR Pyc. PT-BR Scan the code to know more E-mail: cs@creality.com V2.2 V1.0 Material rack Material rack screws M3*18 screws M3*12 ×3 ×1 Tips: the above accessories are for reference only. Please refer to the physical accessories! -
Page 7: Unboxing
2. Unboxing 2.1 Unpacking Steps ① ② ③ ④ ⑤ Remove the power cord and air filter cartridge assembly;. Move the chain to one side in the direction indicated by the arrow; Finally, take the grey foam as shown. 01 04... - Page 8 2. Unboxing ⑥ ⑦ ⑧ Push the extruder in the direction indicatedby the arrow and remove the foam. 01 05...
-
Page 9: Install The Product
2. Unboxing 2.2 Install the Product ① ② Install the air filter cartridge assembly. Install the door handle on the front door as shown in the diagram. ③ Take the touch screen out of the tool box and connect the touch screen to the flat cable extended from the base according to Figure A. Then snap the touch screen into the slot in the baseplate, as shown in Figure B. - Page 10 2. Unboxing ⑤ Connection and power on. ④ Install the material barrel. Use M3*12 screws NOTE: For a different user experience in loading resin, you can use the supplied G-code file to print the material barrel holder and then install it on the side of the machine as shown in the figure above (use the 3 material rack screws to lock it in place, and screw holes have been pre-drilled on the side).
- Page 11 2. Unboxing ⑨ Select a language and click “Next", Remove three screws a, b and c according to position indicated by the yellow arrow. click “OK" on the screen. ⑩ Keep the blue cube in the figure clean of debris and then click“OK". Note: The current interface is for reference only.
-
Page 12: Power-On Guide
2. Unboxing 2.3 Power-on guide Reminder: When the printing time of the device exceeds 300 hours, or ifthe printing platform or nozzles have been replaced, the distance between the platform and nozzles may change that caused the first layer of the model may not stick firmly, resulting in printing failure. Please calibratethe platform regularly. -
Page 13: About The User Interface
3. About the User Interface 3.1 Tune、Prepare Nozzle Temperature Hotbed Temperature Chamber Main temperature This screen allows you to reduce the machine's working volume by selecting the Mute Mode Parameters can be manually set Prepare Print interface LED switch Cooling inlet Print Time Remain Note: The current interface is for reference only. -
Page 14: Files
3. About the User Interface 3.2 Files ① ② Local model Tips: Choosing print calibration can improve print Press and hold on the model to multi-select and copy it to a USB flash drive quality Note: The current interface is for reference only. -
Page 15: Tune、Support
3. About the User Interface 3.3 Tune、Support Help System System Tune Support Error history Network Note: The current interface is for reference only. Due to the continuous upgrading of functions, it shall be subject to the latest firmware UI published on the official website. Upload Log... -
Page 16: First Printing
4. First Printing 4.1 USB flash disk Printing ① ② USB flash drive model Insert the storage device Note: Keep the Extrusion switch lock before printing. ③ Select to print ④ Printing Note: The current interface is for reference only. Due to the continuous upgrading of functions, it shall be subject to the latest firmware UI published on the official website. -
Page 17: Lan Printing
4. First Printing 4.2 LAN Printing Creality Print ① Download at (www.crealitycloud.com) or find the software on a USB flash drive and install it. ② ③ Choose a language and region Choose a Printer Tips: the computer must be in the same... - Page 18 4. First Printing ⑥ Selection of LAN printing ⑦ Add a device: a. Add by scanning → Select a device ⑧ Device List ⑦ Add a device: b. Add a device by manually entering the IP address Note: The current interface is for reference only. Due to the continuous upgrading of functions, it shall be subject to the latest software UI published on the official website.
-
Page 19: Creality Cloud Printing
4. First Printing 4.3 Creality Cloud printing Creality Cloud ① Search for “Creality Cloud" ② Sign up ③ Log in in the App Store, download and install it... - Page 20 4. First Printing Select Settings → Bind the Creality Cloud Scan the QR code ④ ⑤ ⑥ Select model on the ⑦ Slice Add a new device Added successfully homepage Note: The current interface is for reference only. Due to the continuous upgrading of functions, it shall be subject to the latest software UI published on the official website.
-
Page 21: Functional Specification
5. Functional Specification 5.1 Extrude、Filament Retreat Extrude Filament Retreat NOTE: The nozzle temperature must be set Note: The current interface is for reference only. Due to the continuous according to the filament properties. upgrading of functions, it shall be subject to the latest firmware UI published on the official website. -
Page 22: Ai Camera
5.2 AI camera 5.2.1 View the AI camera image using Creality Print or the Creality Cloud App. (The AI camera monitors the printing process, and captures time-lapse photography. The AI detects foreign matters on the platform before printing, and detects printing abnormalities while printing is in progress.) Users have the flexibility to activate AI... - Page 23 5. Functional Specification Method 2： Open “Creality Cloud", click on “Account" – “Print Records" – “Time-lapse Photography" (Note: Creality Cloud must be linked to the device first) Creality cloud Note: The current interface is for reference only. Due to the continuous upgrading of functions, it shall be subject to the latest software UI published on the official website.
- Page 24 5. Functional Specification ： Method 3 1.Click on "Details" 2. Choose "Time-lapse Photography" Note: The current interface is for reference only. Due to the continuous upgrading of functions, it shall be subject to the latest software UI published on the official website. 01 21...
-
Page 25: Tips And Routine Maintenance
① Please visit https://www.crealitycloud.com/product, click “Products" and select the right model, and then click “Related" to view the tutorials on after-sales service; ② Or contact our after-sales service center at +86 755 3396 5666, or send e-mail to cs@creality.com. 6.1 Maintenance Items Maintenance instructions Clean the debris inside the machine to ensure that its operation is not affected. -
Page 26: Precautions For Printing
6. Tips and Routine Maintenance 6.2 Precautions for printing 6.2.1 Lubrication and maintenance Y-axis optic axis 1 X-axis optic axis 1 Y-axis optic axis 2 X-axis optic axis 2 Screw rod 3 Z-axis optic axis 1 Z-axis optic axis 3 Screw rod 1 Z-axis optic axis 2 Screw rod 2... - Page 27 If you want to buy the above flexible platform, you can enter the mall damage the PEI sticker layer https://vip.creality.com/en/goods-detail/2105 for purchase. - When printing with engineering materials like ABS, adhesive is required. It is recommended to use the attached rubber stick or purchase specialized 3D printing adhesives like LALDC/maigoo.
- Page 28 6. Tips and Routine Maintenance ① Together with the flexible platform after the printed ② The residue of the platform filaments ③ When the first layer of the model is not model has been cooled down Remove from the device canbe scraped off...
- Page 29 Since each model is different, the actual product may be different from the picture. Please refer to the actual product. The final interpretation right belongs to Shenzhen Creality 3D Technology Co., Ltd. SHENZHEN CREALITY 3D TECHNOLOGY CO., LTD. Add:18th Floor, JinXiuHongDu Building, Meilong Road, Xinniu Community, Minzhi Street, Longhua District, Shenzhen City, China.
