Name
Aqua stop

1 0.1 Assembling the Wi-Fi Dongle

Info
The Wi-Fi dongle is an independent item and if it is applicable in the region, it needs to be or-
dered separately.
Parts and Tools
Procedure 1. Loosen the screw on the cover.
2. Push the cover to the right and lift it up.
3 . Plug the Wi-Fi dongle into the USB port.
4 . Install the cover.
5 . Tighten the screw.
Instruction Manual ZEISS Axiovert 5 digital | en-US | Rev. 1 | 431030-7021-101
10 Accessories and Optional System Expansions | 10.1 Assembling the Wi-Fi Dongle
Hex Key, 3.0 mm
Description/info
The aqua stop protects the objectives and the nosepiece when
working with liquid samples.
