Fig. 3: Controls and functional elements
6
8
1 0
1 2
Instruction Manual ZEISS Axiovert 5 digital | en-US | Rev. 1 | 431030-7021-101
3 Product and Functional Description | 3.2 Controls and Functional Elements on Components
Focusing drive – fine adjustment
Snap button (right and left side)
Light shield
Carrying handle
6 7 13
7 Focusing drive – coarse adjustment
9 Tablet handles
11 Contrast lever
13 Release lever for adjustable focus stop
9
1 0
1 1
8
1 2
