4 Installation | 4.7 Assembling the Object Guide and Mounting Frame to the Stage

4 .7 Assembling the Object Guide and Mounting Frame to the Stage

Info
The object guide can be mounted to the right or to the left side of the stage.
Procedure 1. Set the object guide onto the stage.
2 . Tighten the three knurled screws to fix the ob-
3 . Slide the mounting frame Flex M into the ob-
4 . If required, put a mounting frame insert onto
2 8
ject guide from below.
ject guide until it snaps into place.
the mounting frame and fix it with the sliders.
Instruction Manual ZEISS Axiovert 5 digital | en-US | Rev. 1 | 431030-7021-101
