CM6200 Install Guide
Placement and Use of Components
DAS Sensor
The DAS sensor monitors forward movement for remote starting manual transmissions in the event that the
vehicle is placed in gear. Follow the steps below to properly setup your DAS sensor.
Installing Your DAS
STEP 1: Set Option 4-12 to Setting 2
STEP 2: Set switch 1 and 2 on the side of the DAS. *See below for explanation or switches.
STEP 3: Connect cable to the red 4 pin port on the CM6 Series module.
STEP 4: Mount DAS securely using zip ties or included hardware. Can be mounted in any orientation. Tilt
will set 30 seconds after locking/arming. Tilt is only enabled if the Factory Style Alarm option is on.
Switch 1:
DAS Sensor
The DAS sensor monitors forward movement for remote starting manual transmissions, dual stage impact,
and auto adjusting tilt sensor. Follow the steps below to properly setup your DAS sensor.
Installing Your DAS
STEP 1: Set Option 4-12 to Setting 2
STEP 2: Set switch 1 and 2 on the side of the DAS. *See below for explanation or switches.
STEP 3: Connect cable to the red 4 pin port on the CM6 Series module.
STEP 4: Mount DAS securely using zip ties or included hardware. Can be mounted in any orientation. Tilt
will set 30 seconds after arming.
Switch 1:
Adjusting DAS Shock Sensitivity (CM6000 or CM6300)
STEP 1: Turn the ignition to the 'on' position.
STEP 2: 2 Way remotes-hold buttons 1 and 2 (Lock and Unlock) for 2.5 seconds. You will get two parking
light flashes. 1 Way remotes-hold Lock and Unlock for 2.5 seconds. You will get two parking light flashes.
STEP 3: To set the Warn Away Zone 1, tap button 1. (1 Way: Lock) After you get one parking light flash,
tap the vehicle. You will get siren chirps 1-most sensitive through 10-least sensitive. This sets the impact
sensitivity of Warn Away Zone 1. Setting Zone 1 will automatically set Zone 2. If you would like
to manually set Zone 2 proceed:
To set Instant Trigger Zone 2, tap button 2. (1 Way: Unlock) After you get two parking light flashes, tap the
vehicle. You will get siren chirps 1-most sensitive through 10-least sensitive. This sets the impact sensitivity of
Instant Trigger Zone 2.
Copyright 2012 Firstech, LLC.
ON - 3 Degree Tilt
OFF - 1.5 Degree Tilt
ON - 3 Degree Tilt
OFF - 1.5 Degree Tilt
www.firstechonline.com | www.compustar.com
Switch 2: ON - 4 Inch Movement
OFF - 3 Inch Movement
Switch 2: ON - 4 Inch Movement
OFF - 3 Inch Movement
Starter System
CM6200
