3-15 Soft Disarm - When a vehicle has factory security, and the Firstech alarm is triggered, you may have
both alarms sounding at the same time. In the default setting, silencing the Firstech system will not
shut down the factory system, therefore requiring the user to first silence the Firstech system (by
tapping unlock 1 time) and then unlock a 2nd time to silence the factory system. Option2 will send
the Factory Alarm Disarm (orange white wire CN3 or any other POC programmed as FAD) and 5
seconds later sends rearm pulse (orange wire CN3) to ensure the doors re-lock if needed. (only
available with feature 3-06 option 2)
4-01 Aux 1 Output - This feature determines the duration of the auxiliary 1 output. (Option 4 allows the
output duration to be set for a specific length of time 1-99 sec. only available when using the
OP500)
4-02 Aux 2 Output - This Feature determines the duration of the auxiliary 2 output. (Option 4 allows the
output duration to be set for a specific length of time 1-99 sec. only available when using the
OP500)
4-03 Aux 1 Output Control - This feature allows the user to configure the method of which Auxiliary 1 can
be activated. (Option 4 will activate AUX 1, for a set period of time based off of feature 4-01, as
soon as ignition input to the CM is removed)
4-04 Aux 2 Output Control - This feature allows the user to configure the method of which Auxiliary 2 can
be activated. (Option 4 will activate AUX 2, for a set period of time based off of feature 4-02, as
soon as the CM receives the start command)
4-05 Secure Aux Output – This feature, in the default option should help prevent accidental activation
of the AUX outputs. (2way remotes will require button IV or start button to be tapped before
activating any of the AUX outputs. 1way remotes require the user to hold trunk+start buttons for 2.5
seconds before activating AUX outputs Option setting II turns this feature off.)
4-08 Extended Accessory after Ignition Shutoff – This option keeps the Accessory wire powered up after
the ignition is shut off. This can be used to keep the radio turned on even after the key is removed
from the ignition (similar to GM vehicles).
4-09 Glow Plug or Key Sense – Default setting sets the wire as a glow plug input. Option setting 2
changes the wire to a key sense input. Key sense can be used to prevent reservation mode from
setting and the system from passive arming while the key is still in the ignition. Key sense also turns
off dome-light supervision when the key is inserted into the ignition. Option 3 will provide an arm/
disarm disable input wire (input polarity jumper selectable on the CM) to work with analog arm/lock
disarm/unlock input (using green CN8 with CM6000-CM6300) (using red CN6 with CM6200)
