CM6200 Install Guide
Connector 10 (CN10), 2-Pin (Pre-wired LED)
Note: Do not mistake for Thermister port.
Pin 1 Black - L.E.D negative (-) ground.
Pin 2 Black/White- L.E.D. 3V positive (+) output.
Connector 11 (CN11), 3-Pin (Pre-wired Valet/Programming Switch)
Pin 1 Gray/Black - Negative (-) ground.
Pin 2 Gray – 3V positive (+) L.E.D. output.
Pin 3 Gray – Negative (-) output.

Option Programming Tables

Feature
Unlock before, Lock after, starting
1-01
Lock / Unlock pulse duration
1-02
Driver's priority unlock
1-03
Double pulse unlock
1-04
Rearm Output
1-05
Reservation Lock
1-06
(Manual transmissions)
Unlock / Disarm With Trunk
1-07
Release
Passive Mode
1-08
Ignition controlled door locks
1-09
Auto Relock
(If a door is not opened within
1-10
this amount of time)
Ignition / Accessory Out Upon
1-11
Unlock
1-13 Double Pulse Disarm Input
Auto Mode
1-14
Trunk Output Timing
1-15
Copyright 2012 Firstech, LLC.
Option Group 1
Default Setting - I Optional Setting - II
Off
0.8 sec
Off
Off
After Start Shutdown and After Start Shutdown and
First Lock
Hold Start Button for
Locks Before Reservation
2.5 sec. to Activate
Mode is Set
Reservation Mode
Unlock, Factory Disarm, Factory Disarm, Trunk
and Trunk Release
Passive locking with
Off
Off
Off
Ignition Pulse - same
Off
timing as disarm pulse
Single Pulse
FT-EZGO Unlock for
Off
1 sec
www.firstechonline.com | www.compustar.com
Optional Setting - III Optional Setting - IV
Lock After Remote Start
On
2.5 sec 0.125 sec
On
Unlock
After Start Only
Every Lock
Reservation Sets 10
Seconds After the Last
Door is Closed
Trunk Release Only
Release Only
No Passive Locking with
Passive Arming Passive Arming
RPM Locks (Tach Sensing
On
Mode Only)
30 sec
Acc Pulse - same timing
as disarm pulse
Double Pulse
FT-EZGO Unlock
FTX
2 sec
Starter System
CM6200
Lock After Shutdown
Only Only
3.5 sec
Lock Both Lock and Unlock
After Shutdown Only
Locks After Reservation
Mode is Set
60 sec 5 min
Ignition and Acc Pulse -
same timing as disarm
pulse
FT-EZGO Lock and
Unlock
3 sec 4 sec
Page 19
