Special Option Groups 1 & 2
IMPORTANT: The OP500 is required to change settings in Special Option Groups 1 and 2.
Special Option Group 1
1 Diesel Timer – Option 2-03 must first be set to setting 2. This special option allows a specific wait to
start time (in seconds) to be programmed. This prevents the need for a timer relay and eliminates a
connection to the "wait to start" wire.
2 Aux 1 Output Timing – Option 4-01 must first be set to setting 4. This special option allows a
specific output duration for Aux 1 to be programmed.
3 Aux 2 Output Timing – Option 4-02 must first be set to setting 4. This special option allows a
specific output duration for Aux 2 to be programmed.
4-8 Aux 3 – 7 Output Timing – Option 3-11 must first be set to setting 2 and the optional Auxiliary
settings module must be used. These special options allow specific output durations to be set for Aux
3 – 7. Only available with 2 Way LCD remotes.
Special Option Group 2
This special option group allows you to determine the output type of the POC wires. For example, if you
want to set POC #5 (default setting status out) to Aux 1, you will need change special option 5 to number
10. This must be done with the OP500.

Option Programming

Option Programming Using the OP500 (programmer)
The OP500 can be used to program any available option. It is required to program options in Special Op-
tion Groups 1 and 2.
STEP 1: Make sure system is unlocked/disarmed. Using the blue connector on the top of the
OP500, connect it to the control module via the antenna wire. (Use the included extension cable if neces-
sary.) Once connected, the OP500 will power up as long as the main ignition harness to the controller has
been connected properly.
STEP 2: To change the option number you wish to program, use the left and right arrow keys on the
OP500. It will scroll through the options available in menu 1 and then move to menu 2, then 3 and 4. Use
the up and down arrow buttons on the OP500 to adjust the option settings; "1" is the default setting, and
"2", "3", and "4" are the optional settings.
