CM6200 Install Guide
1-06 Reservation Lock - Manual transmission only; Option 2 requires the user to initiate start sequence
with the remote to enter reservation mode. Option 3 will provide a 10 second delay after closing
the last door before the vehicle shuts off to allow for another door to open. Upon a door opening,
the user will have 2 minutes to close the last door in order for reservation mode to set. option 4 will
set the unit to lock after reservation mode is set.
1-07 Unlock / Disarm with Trunk Release - This option allows the user to configure or disable the unlock/
disarm outputs that trigger with the trunk release command.
1-08 Passive Mode - This option comes with default off. This feature controls what the lock wire does
during passive mode. Passive must also be activated by the end user remote according to the
process specified in the remote user's manual.
1-09 Ignition Controlled Locks - Setting 2 will lock the doors when the foot brake is pressed and doors
closed. Tach sensing mode must be used for setting 3.
through the remote by tapping I+IV (2 Way remotes) or Lock+Key (1 and 2 Way remotes).
1-10 Auto Relock – This option will automatically relock/rearm at the selected timed if system has been
disarmed and the doors have not been opened.
1-11 Ignition / Accessory Upon Unlock – This option will pulse the ignition wire, accessory, or both upon
unlock/disarm i.e. Most new Ford vehicles require ignition pulsed+immobilizer with unlock to
disarm the factory alarm.
1-13 Double pulse disarm - This feature changes the behavior of the small orange/white disarm wire.
When the feature is turned on it will change the default single pulse to double pulse upon disarm/
unlock.
1-14 Auto Mode (EZ-GO)- This feature enables the RFID EZ-GO functions according to the option
selected. Once selected and the EZ-GO remote has been programmed to the Control Module the
user can activate/deactivate the proximity function by holding the button on the back of the RFID
remote for 10 seconds.
Option 2: will keep the EZ-GO antenna awake and allow the system to unlock every time the
RFID remote is within proximity of the EZ-GO antenna regardless of the state of the control module
(i.e. locked/armed or unlocked/disarmed)
Option 3: will allow the RFID remote to proximity unlock the system after it has been outside
proximity of the EZ-GO antenna and the control Module has been locked/armed for at least 15
seconds.
Option 4: will allow the system to arm/lock aprox. 12 seconds after the RFID remote leaves proximity
of the EZ-GO antenna and allow it to unlock the system as the user approaches the vehicle and is
within the proximity of the EZ-GO antenna.
1-15 Trunk Output Timing - This option changes the time of the output pulse on the violet/white wire
during trunk release. The default setting is 1 second. With the options you can extend the
output by 2, 3 or 4 seconds to a maximum of 4 seconds.
