Introduction

The Transition Networks SPOEB10xx-105 Power over Ethernet (POE) converter is a two port 10/100Base-TX to
100Base-FX media converter capable of providing power to Data Terminal Equipment (DTE) Power Devices (PD)
via the Media Dependent Interface (MDI) twisted pair cable. The SPOEB10xx-105 emulates Power Sourcing
Equipment (PSE) and provides power via the 10/100Base-TX interface for a remote PD device that complies with
™
the IEEE802.3af standard.
The SPOEB10xx-105 lets enterprises provide power to network devices over the existing CAT5 data connection.
Transition Networks' AC powered PoE media converters combine data received over a fiber optic link with
-48VDC power; providing power to Data Terminal Equipment (DTE) Power Devices (PD) over unshielded twisted
pair (UTP) cable. The PoE converters are Power Sourcing Equipment (PSE) and are fully compatible with
Powered Devices (PDs) that comply with the IEEE802.3af™: 2003 standard. The converters also include PD
signature sensing and power monitoring features per the IEEE 802.3af standard. Other features include Over-
Current Protection, Under-Current Detection, and Fault Protection Input. This feature-enhanced model offers the
ability to enable/disable many of the features as well as force port capabilities. In addition, with the PSE/LPT
switch enabled, a loss of Fiber RX will disable PSE power output on the UTP port for two seconds to allow the
remote device to re-initialize.
The PoE converter is fully compatible with devices that comply with the IEEE802.3af standard. The PoE converter
is capable of inserting power on data pairs of the MDI.

Product Description

Models

Number
SPOEB1039-105
SPOEB1040-105
SPOEB1011-105
SPOEB1013-105

Optional Accessories

Part Number
WMBL
WMBD
WMBV
RMS19-SA4-01
SFP Modules

Distances

Number
SPOEB1039-105 (LC)
SPOEB1040-105 (SFP)
SPOEB1011-105 (ST)
SPOEB1013-105 (SC)
Cable distances are typical maximum distances. Actual distance depends on the physical characteristics of
*
the network installation.
33618 Rev. C
10/100Base-TX RJ-45 PoE to 100Base-FX MM LC 2km
10/100Base-TX RJ-45 PoE to 100Base-FX Open SFP Slot
10/100Base-TX RJ-45 PoE to 100Base-FX MM ST 2km
10/100Base-TX RJ-45 PoE to 100Base-FX MM SC 2km
Wall Mount Bracket: Length: 4.0 in. (102 mm), fits converter length: 4.7 in. (119mm)
DIN Rail Mount Bracket; Length: 5.0 in. (127 mm)
Vertical Wall Mount Plate; Length: 5.0 in. (127 mm)
4-Slot Media Converter Shelf
Transition Networks offers a full line of
Port One - Copper
10/100Base-TX
RJ-45 PoE; 100 m (328 ft.)
RJ-45 PoE; 100 m (328 ft.)
RJ-45 PoE; 100 m (328 ft.)
RJ-45 PoE; 100 m (328 ft.)
https://www.transition.com/
Description
Description
SFP Transceivers.
Port Two - Duplex Fiber-Optic
100Base-FX
LC, 1300nm multimode, 2km (1.2 miles)
*
SFP, open slot
*
ST, 1300 nm multimode; 2 km (1.2 miles)
*
SC, 1300 nm multimode; 2 km (1.2 miles)
*
