COMPLIANCE INFORMATION

UL Listed
C-UL Listed (Canada)
CISPR/EN55022 Class A
FCC Regulations
This equipment has been tested and found to comply with the limits for a class A
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at the
user's own expense.
Canadian Regulations
This digital apparatus does not exceed the Class A limits for radio noise for digital
apparatus set out on the radio interference regulations of the Canadian Department of
Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les
limites applicables aux appareils numériques de la class A prescrites dans le
Règlement sur le brouillage radioélectrique édicté par le ministère des
Communications du Canada.
European Regulations
Warning
This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
Achtung !
Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei
Betrieb dieses Gerätes Rundfunkstörungen auftreten, in weichen Fällen der Benutzer
für entsprechende Gegenmaßnahmen werantwortlich ist.
Attention !
Ceci est un produit de Classe A. Dans un environment domestique, ce produit risque
de créer des interférences radioélectriques, il appartiendra alors à l'utilsateur de
prende les measures spécifiques appropriées
Trademark Notice
All registered trademarks and trademarks are the property of their respective owners.
Copyright Restrictions
© 2003 TRANSITION Networks.
All rights reserved. No part of this work may be reproduced or used in any form or
by any means – graphic, electronic, or mechanical – without written permission from
TRANSITION Networks.
Printed in the U.S.A.
16
33236.A
High-Speed Serial Copper-to-Fiber
Slide-in-Module Media Converters
SPSVT26xx-100
USER'S GUIDE
TRANSITION Networks
SPSVT26xx-100 series high-speed
serial copper-to-fiber media
converters connect V.35, X.21,
RS-449, RS-530, or RS-232 signals on
copper cable, at speeds up to
10 Mb/s, through a universal
26-pin serial interface connector
to fiber-optic cable. TRANSITION
Networks also supplies cables for
connecting network equipment
to the SPSVT29xx-100 series
media converters.
SPSVT2613-100 Copper high-speed serial 26-pin connector and
SC connector to 1300 nM multimode fiber
SPSVT2611-100 Copper high-speed serial 26-pin connector and ST
connector to 1300 nM multi-mode fiber
SPSVT2612-100 Copper high-speed serial 26-pin connector and
ST connector to 1300 nM singlemode fiber
SPSVT2614-100 Copper high-speed serial 26-pin connector and SC
connector 1300 nM singlemode fiber
SPSVT2629-100/ Set of two media converters to be installed
SPSVT2629-101 together, each high-speed serial 26-pin connector
and RX and TX single fiber connector to
singlemode 20 km fiber-optic cable
SPSVT2629-102/ Set of two media converters to be installed
SPSVT2629-103 together, each high-speed serial 26-pin connector
and RX and TX single fiber connector to
singlemode 40 km fiber-optic cable
