speeds up to 10 Mb/s, through a universal 26-pin serial interface connector to fiber-optic
cable. Transition Networks also supplies cables for connecting network equipment to the
SPSVT26xx-10x series Device.
Part Number
Port One - Copper Port Two - Duplex Fiber-Optic
SPSVT2611-100 Universal 26-pin
serial interface*
SPSVT2613-100 Universal 26-pin
serial interface*
SPSVT2614-100 Universal 26-pin
serial interface*
SPSVT2615-100 Universal 26-pin
serial interface*
* For typical maximum cable distance, see Cable Specifications section.
** Typical maximum cable distance. Actual distance is dependent upon the physical
characteristics of the network installation.
The chassis version of this Device is CPSVT26xx-10x. For more information, see the
user's guide for the CPSVT26xx-10x on-line at www.transition.com
User's Guide
SPSVT26xx-10x
Stand Alone Device
• High-Speed Serial
• V.35/X.21/RS449/RS530/RS232
• Copper to Fiber
Transition Networks SPSVT26xx-10x
series high-speed serial copper-to-fiber
Device connect V.35, X.21, RS-449, RS-
530, or RS-232 signals on copper cable, at
ST, 1300 nm multimode
2 km (1.2 miles)**
SC, 1300 nm multimode
2 km (1.2 miles)**
SC, 1310 nm single mode
20 km (12.4 miles)**
SC, 1310 nm single mode
40 km (24.9 miles)**
Cable Options . . . . . . . . . . . . . . . . . .3
Installation . . . . . . . . . . . . . . . . . . . . .4
Operation . . . . . . . . . . . . . . . . . . . . .9
Cable Specifications . . . . . . . . . . . . .10
Technical Specifications . . . . . . . . . .12
Troubleshooting . . . . . . . . . . . . . . .13
Contact Us . . . . . . . . . . . . . . . . . . .15
Compliance Information . . . . . . . . .16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPSVT26xx-10x and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Transition Networks SPSVT26xx-10x

  • Page 1: Table Of Contents

    Device connect V.35, X.21, RS-449, RS- 530, or RS-232 signals on copper cable, at speeds up to 10 Mb/s, through a universal 26-pin serial interface connector to fiber-optic cable. Transition Networks also supplies cables for connecting network equipment to the SPSVT26xx-10x series Device. Part Number...
  • Page 2: Cable Options

    SPSVT26xx-10x Device. The SPSVT2629-100 and the -101 are intended to be installed in Each cable (available from Transition Networks) is 3 meters in length and has a the same network where one is the local Device and the other is the male universal 26-pin serial connector at one end.
  • Page 3: Installation

    SPSVT26xx-10x Installation Installation — Continued CAUTION: Wear a grounding device and observe electrostatic discharge Set the Loop-Back Switch precautions when setting the switches and jumpers. Failure to observe this caution The loop-back switch is located on the front panel of the Device and is used to could result in damage to, and subsequent failure of, the Device.
  • Page 4 Set the Jumpers J6- RX Clock Polarity Jumper The SPSVT26xx-10x has three jumpers located on the circuit board inside the Device housing. To set any of the three jumpers: Using a small screwdriver, remove the four (4) screws that secure the cover and carefully remove the cover from the Device.
  • Page 5: Operation

    Device. • Connect the male RX cable connector to the female TX port. Operation Status LEDs Use the status LEDs to monitor the SPSVT26xx-10x Device operation in the network. Device Device (on) The Device is connected to external power.
  • Page 6: Cable Specifications

    -14.0 dBm The five high-speed serial cables (available from Transition Networks) that are Fiber Optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm compatible with the 26-pin copper port on the SPSVT26xx-10x Device are the Link Budget: 11.0 dB following: SPSVT2613-100 1300 nm multimode •...
  • Page 7: Technical Specifications

    • Proceed to step 3. The information in this user’s guide is subject to change. For the most up-to-date information on the SPSVT26xx-10x Device, see the user’s guide on-line at Is the FL LED on the Device illuminated? www.transition.com. •...
  • Page 8: Contact Us

    International: 00-1-952-941-7600 Transition Now Local Remote Chat live via the Web with Transition Networks Technical Support. Device Device Log onto www.transition.com and click the Transition Now link. Web-Based Seminars •...
  • Page 9: Compliance Information

    In accordance with European Union Directive 2002/96/EC of the European Parliament and of the Council of 27 January 2003, Transition Networks will accept post usage returns of this product for proper disposal. The contact information for this activity can be found in the 'Contact Us' portion of this document.
