2 EVM Analog Interface

The ADS8332EVMV2 is designed for easy interfacing to analog sources. The Samtec
a convenient 16-pin, single-row, header J1 accessing channels IN0-IN7 of the device. In addition, four SMA
connectors, J-1 to J-4, provide a high quality connection to channels IN0, IN1, IN6, and IN7.
the ADS8332EVMV2 analog input connections, input buffers, and input RC filters for channels IN0 to IN7.
2-1 lists the analog interface connections for header J1 and
the SMA connectors.
SMA Connector
J5
SMA Connector
J8

Figure 2-1. ADS8332EVMV2 Analog Input Connections for Channels IN0 to IN7

SBAU251B – JULY 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
Table 2-2
J1
1 k
¤
1
2
1 k
£
15
16
JP1
0.2-V Supply
Copyright © 2023 Texas Instruments Incorporated
™
connector provides
lists the analog interface connections for
ADS8332
40.2
¡
IN0
1500 pF
40.2
¢
IN7
1500 pF
40.2
COM
1500 pF
ADS8332EVMV2-PDK Evaluation Module
EVM Analog Interface
Figure 2-1 shows
Table
5
