5 ADS8332EVMV2-PDK Initial Setup

This section explains the initial hardware and software setup procedure that must be completed for the proper
operation of the ADS8332EVMV2-PDK.

5.1 Default Jumper Settings

Make sure jumpers JP1, JP2, and J4 are in the default configuration while interfacing the ADS8332EVMV2
board with the PHI controller as described in
types of operation.
Figure 5-1 details the default jumper
Jumper Function
JP1 Common pin voltage
JP2 Multiplexer output buffer
J4 EEPROM write enable
SBAU251B – JULY 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
Table 5-1. The jumpers can be reconfigured to allow for different
settings.Table 5-1

Figure 5-1. ADS8332EVMV2 Default Jumper Settings

Table 5-1. Default Jumper Configuration

Default Position
Shunt on pins 2-3
Shunt on pins 1-2
Open
Copyright © 2023 Texas Instruments Incorporated
explains the configuration for these jumpers.
Shunt on pins 2-3 select ground as the common pin voltage
Shunt on pins 1-2 selects to bypass the buffer between
MUXOUT and ADCIN
Open enables write protect for the EEPROM
ADS8332EVMV2-PDK Evaluation Module
ADS8332EVMV2-PDK Initial Setup
Description
