Figure 7-9. Ads8332Evmv2-Pdk Schematic: Hardware - Texas Instruments ADS8332EVMV2-PDK User Manual

Bill of Materials, PCB Layout, and Schematics
28 ADS8332EVMV2-PDK Evaluation Module
H1 H2 H3
PMSSS 440 0025 PH PMSSS 440 0025 PH PMSSS 440 0025 PH
H7 H8
H9 H10 H11
1891 1891 1891
RM3X4MM 2701 RM3X4MM 2701
DNP DNP DNP
FID1 FID2 FID3
PCB Number: PA011 PCB
LOGO
PCB Rev: A
Texas Instruments
ZZ1
Assembly Note
These assemblies are ESD sensitive, ESD precautions shall be observed.
ZZ2
Assembly Note
These assemblies must be clean and free from flux a nd all contaminants. Use of no clean flux is not ac ceptable.
ZZ3
Assembly Note
These assemblies must comply with workmanship stand ards IPC-A-610 Class 2, unless otherwise specified.

Figure 7-9. ADS8332EVMV2-PDK Schematic: Hardware

Copyright © 2023 Texas Instruments Incorporated
H4
H5 H6
9774050360R 9774050360R
PMSSS 440 0025 PH
H13
H12
MECH
Edge# 6591636 rev. B
PHI-EVM Controller
1891
SH-J1
PCB PCB
LOGO LOGO
Pb-Free Symbol FCC disclaimer
www.ti.com
SH-J2
SBAU251B – JULY 2017 – REVISED FEBRUARY 2023
