Technical Specifications
EXT3-XR-TR Specifications
Inputs
Outputs
Ports
Extension Line
Video
Extended USB
Extended Ethernet
Extended RS-232
Power
Environmental
Conditions
Regulatory
Compliance
Enclosure
General
Accessories
Specifications are subject to change without notice at
EXT3-XR-TR, EXT3-TR – Technical Specifications
Transmitter Side
1 HDMI
Receiver Side
1 HDBT
Transmitter Side
1 HDBT
1 LOOP
Receiver Side
1 HDMI
1 USB 2.0 Host
3 USB 2.0 Device
1 1000BaseT Ethernet
1 IR
1 RS-232
Reach
Standards Compliance
Max Data Rate
Max Resolution
Content Protection
HDMI Support
Data Rate
Transmitted Data Bandwidth
Standards Compliance
Max Data Rate
Baud Rate
Consumption
Source
Operating Temperature
Storage Temperature
Humidity
Safety
Environmental
Size
Material
Cooling
Net Dimensions (W, D, H)
Shipping Dimensions (W, D,
H)
Net Weight
Shipping Weight
Included
On a female HDMI connector
On a female RJ-45 connector
On a female RJ-45 connector
On a female HDMI connector
On a female HDMI connector
On a USB-B female connector
On USB type-A female connectors
On an RJ-45 female connector for LAN extension
On a 3.5mm mini jack for IR link extension
On a 3-pin terminal block for serial link extension
Up to 100m (330ft), when using Kramer HDBaseT
cables
HDBaseT 3.0
18Gbps bandwidth (6Gbps per graphic channel)
4K@60Hz (4:4:4) 24bpp resolution
HDCP 2.3
4K as specified in HDMI 2.0b
Up to 480Mbps
Up to 300Mbps
1.1 and 2.0 USB
1Gbps
300 to 115200
12V DC, 1950mA
12V DC, 5A
0° to +40°C (32° to 104°F)
-40° to +70°C (-40° to 158°F)
10% to 90%, RHL non-condensing
CE
RoHs, WEEE
Mega Tool
Aluminum
Convection Ventilation
19cm x 11.6cm x 2.7cm
(7.5" x 4.6" x 1.1")
34.5cm x 16.5cm x 5.2cm
(13.6" x 6.5" x 2")
0.56kg (1.2lbs)
1.15kg (2.5lbs) approx.
Power adapter and cord
www.kramerav.com
Kramer Electronics Ltd.
12
