Technical Specifications

INPUTS:
OUTPUTS:
SYSTEM CABLE:
OPERATING TEMPERATURE:
STORAGE TEMPERATURE:
HUMIDITY:
DIMENSIONS:
WEIGHT:
ACCESSORIES:
Specifications are subject to change without notice
5.1

9-pin D-sub Pin Connections

Pin
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
Pin 9
6
RS-232 on a 9-pin D-sub F connector (local unit)
CAT 5 on an RJ-45 connector (remote unit)
CAT 5 on an RJ-45 connector (local unit)
RS-232 on a 9-pin D-sub M connector (remote unit)
CAT 5 UTP/FTP 2x4x24AWG solid wire cable
0° to +40°C (32° to 104°F)
-40° to +70°C (-40° to 158°F)
80% RHL non-condensing
75mm x 45mm x 25mm (3.0" x 1.8" x 1.0")
120g
12V DC, 1A power supply
Function
N/C
Receive data
Transmit data
Data terminal ready
Signal ground
Data set ready
Request to send
Clear to send
N/C
