Connecting to EXT3-XR-TR via RS-232

You can connect to
EXT3-XR-TR features an RS-232 3-pin terminal block connector to extend RS-232 signals via
EXT3-XR-TR transmitter and receiver.
Connect the RS-232 terminal block on the rear panel of
From the RS-232 9-pin D-sub serial port connect:
•
Pin 2 to the TX pin on the
block
•
Pin 3 to the RX pin on the
block
•
Pin 5 to the G pin on the
block

Wiring RJ-45 Connectors

This section defines the HDBT pinout, using a straight pin-to-pin cable with RJ-45 connectors.
It is recommended that the cable ground shielding be connected/soldered to the connector
shield.
EIA /TIA 568B
PIN Wire Color
1 Orange / White
2 Orange
3 Green / White
4 Blue
5 Blue / White
6 Green
7 Brown / White
8 Brown

Setting the DIP-Switches

All changes in the SETUP rear panel DIP-Switches
to power cycle the device), except for DIP-switches 1 and 2.
EXT3-XR-TR, EXT3-TR – Connecting the 4K60 HDMI/USB Extender
EXT3-XR-TR via an RS-232 connection
EXT3-XR-TR
EXT3-XR-TR
EXT3-XR-TR RS-232 terminal
13
EXT3-XR-TR
RS-232 Device
RS-232 terminal
RS-232 terminal
18
apply immediately, on-the-fly (no need
Kramer Electronics Ltd.
using, for example, a PC.
to a device, as follows:
EXT3-XR-TR
10
