AMP-204C / AMP-208C
Velocity
Pre-distance
Post-distance
Time
Pre-distance event
(PRED)
Post-distance event
(POSTD)
Motion done event
(MDN)
Time
Figure 4-51: Relation between pre- and post-distance event signals and
movement
Motion Control Theory
131
