Cables and connecting plugs on the control unit
230 V power cable
230 V cable for output with plug
for solenoid valve
Cable X10 for communication
module
10. Electrical connections
230 V cable for output with
safety (Schuko) plug
230 V cable for output
(UV module & submersible
pump)
Plug X12 for 24 V inputs and
outputs
96 / 137
230 V cable for output with
Phoenix (terminal) plug
24 V cable for output to step mo-
tor valves
Plug X20 for contactor monitor-
ing
