Modules - Graf oneAdvanced Operation Manual

8.2.9

Modules

This menu can be used to steer and monitor additional modules.
Service » Modules
C module
P module
Chlorination module
UV module
8. Service menu for authorised specialist
Additional dosing from an external carbon source.
Setting the operating parameters for dosing pumps. In addi-
tion, level monitoring can be activated for the canister (see
Subsection 9.3.4 on page 87).
Setting the simultaneous phosphate precipitation in the SBR
reactor.
Setting the operating parameters for the dosing pumps. In ad-
dition, level monitoring can be activated for the canister (see
Subsection 9.3.3 on page 84).
Setting a tertiary cleaning stage for the disinfection of
wastewater with a chloride solution.
Setting the operating parameters for one or more dosing
pumps. In addition, monitoring can be activated for the canis-
ter (see Subsection 9.3.5 on page 88).
Setting a tertiary cleaning stage for the disinfection of
wastewater with UVC.
Setting the operating parameters for a UV emitter, either with
a pump (time controlled) or with a float switch (level con-
trolled).
The emitter's maximum service life can be set. After the ser-
vice life, a message appears prompting the replacement of the
emitter (see Subsection 9.4 on page 90).
72 / 137
