Start times
Valve size
Restart cycle
Assigning outputs
T-settings
8.2.1

Overview of processes, systems, and discharge classes

There are a total of 7 cleaning processes with up to 4 discharge classes each to choose from.
1
SBR
Process
4V
KLARO
Klaro
Easy
EPro
System
Graf prof
one
Advanced
Demo
Dis-
charge C/N/D/D+
class
These instructions describe exclusively oneAdvanced plants with two (2V, oneAdvanced 3–
9 PE) and four valves (4V, oneAdvanced larger than 10 PE). These must therefore be selected.
8. Service menu for authorised specialist
Editing the cycle start times. Each process comes with its
own start time defaults. The number of cycles can be edited
in the "T-settings" submenu.
NOTE The edited start time is adopted only when ALL start
times are confirmed with [OK].
The size of the fitted step motor valves is selected to ensure
that the right stroke is executed. These values are ½", 1", and
2".
After editing the cycle settings, you should afterwards restart
the cycle. The current treatment cycle is aborted, and the
control unit switches to "Cycle pause" until the next start time
is reached. Otherwise, the current cycle is ended with the old
settings and then the next cycle with the new ones.
The electric components/consumers can be assigned here a
control unit output. Preassigned functions and outputs ap-
pear, which can be selected and edited. Additional consumers
added later must be assigned to the corresponding output if
they too are to be addressed by the control unit. See Subsec-
tion 8.2.2 for an overview of the functions and outputs.
For viewing and editing each of the T-settings (work steps)
and the number of treatment cycles. See Subsection 8.2.1.1
for further details.
2 3
SBR MAX SBR MAX
4V 3V
KLARO KLARO
MAX MAX
- container
- -
- -
- -
Demo Demo
C/N/D C/N/D
4
SBR One
SBR One 3V
KLARO
KLARO One
KLARO
easyOne
One+
one2clean
easyOne
one2clean+
Advanced
one
Advanced
Demo
C/N/D
61 / 137
5 6
Flow
2V 2V
Logo
One
Fixed bed
Fluidised
+ bed
one
-
EClean -
Demo Demo
C/N/D C/N
7
Flow
1V
Moving
bed
Fixed
bed
Fluid-
ised
bed
-
-
Demo
C/N
