4. The wastewater treatment system's control unit

4.4 Operator menu

4.4.1 Information menu – show operating hours, settings, sensor values
Information
Operating hours tot.
Operating hours this week
Operating hours last week
Workload
Show all settings
Version
Show current + voltage
This presents the total operating hours generated by the out-
puts.
Outputs that have not generated operating hours are hidden.
The remaining runtime of the UV lamp is given in brackets.
This presents the operating hours generated during the week
since midnight on Monday.
This presents the operating hours generated during the previ-
ous week from midnight on Monday to 11:59 pm on Sunday.
This presents the utilised capacity of the wastewater treat-
ment plant in level-dependent mode (ratio of treatment cycles
actually performed to standard possible treatment cycles in
percent)
This presents all settings on the service level.
These settings cannot be edited.
This presents the firmware version currently in use
This presents the measurements returned by the current and
voltage sensors.
U_eff (~AC): V
I_eff (~AC): mA current drawn by the 230 V consumers
U_out (24 V): mV internal voltage for 24 V consumers
I_out (24 V): mA current drawn by the 24 V consumers
34 / 137
applied mains voltage
