9.6 External warning indicator

A warning lamp can be connected to one of the 24 V outputs. The output X12.5 has been con-
figured as the factory default for the warning lamp. The output for the warning lamp is configured
in the menu "Service", "Cycle settings", "Assign outputs". The warning lamp is activated at
the same time as the buzzer. The warning lamp and the buzzer are switched OFF when the fault
message has been acknowledged in the menu.

9.7 Actuate solenoid valves

KLcontrol.M can also be used to operate solenoid valves (230 V) in lieu of step motor valves
(24 V).
Procedure:
1. Open the menu Service » Cycle settings » Assign outputs.
2. Select the valve you want and the 230 V output (X32–35) connected to the solenoid valve.
You are then prompted with "Deactivate compressor Yes/No".
3. Select <No>.
The compressor is necessary and may not be deactivated.
The valve and compressor are always switched ON and OFF together.
Normally, the current monitor need not be adjusted
