8.2.2

Outputs

Prior to shipping, the output functions and assignments have been provided with the defaults
listed in the following table. Additional components must be connected accordingly if the switch
cabinet wiring is to continue complying with the circuit diagrams (clarity).
Function KLcontrol.M
Valve 1
Valve 2
Valve 3
Valve 4
Function KLcontrol.M
Compressor 1
Compressor 2
UV module
Cooling fan 1
Cooling fan 2
Pump
Dosing pump 1
Dosing pump 2
Dosing pump 3
Warning lamp
Cooling fan 3
Output 24 V
Multiple outputs must be interpreted as "either or". Each output can be used once only.
NOTE
A compressor is assigned as standard to the valves. After confirming your selection, you are
prompted with "Deactivate compressor Yes/No". If pneumatic lifters are to operate, press [◄]
"No". If submersible pumps are to operate, press [►] "Yes". For the use of submersible pumps,
see also Subsection 9.5 on page 91.
8. Service menu for authorised specialist
Note
X16.1 Standard assignments for transport processes with pneu-
matic lifter via step motor valves. Alternatives also include
X16.2
solenoid valves (see
Subsection 9.5
X16.3
(see
X16.4
Note
X31 If only one compressor, always select "Compressor 1"
X32 Runs in parallel to compressor 1.
For monitoring, check the current threshold settings.
X33
X34 Cooling fan 230 V
X35 Cooling fan 230 V
X32 For submersible pump, e.g. for secondary buffer. Operating
parameters via "reserve module"
X12.7 C module
X12.1 P module
X12.5 Chlorination module
X12.5 External warning lamp 24 V
X12.3 Cooling fan 24 V
... Reserve
Subsection 9.7
).
64 / 137
) or submersible pumps
