Operating pressure
monitoring
Lifter calibration
8. Service menu for authorised specialist
This lets you configure the parameters for pressure monitor-
ing (see Subsection 9.2).
Activate
Yes/No
Measured values
This reads out the measurements, together with their time
stamps, stored for compressor 1, valve 1–4. Saved measure-
ments can be deleted; this does not affect the values from the
teach-in phase.
Limit values
This reads out the limit values for compressor 1, valve 1–4
detected during the teach-in phase. If this teach-in phase is
still active, the limit values are 0.
Reset
Restart of the teach-in phase.
oneAdvanced 3–9 PU (one-tank systems)
This starts the service calibration for level measurements via
the membrane pipe aerator. Same calibration process as with
code 8 8 8 8 (see Subsection 9.1.4).
oneAdvanced larger than 10 PU (with preliminary clean-
ing / sludge reservoir)
The service calibration for level measurements via the charg-
ing lifter are also started with the service code 9 9 9 9 (see
Subsection 9.1.4).
