8.2.1.1 Table layouts
The table is divided into work steps, e.g. feed, and runtime calculations. Also the number of
cleaning cycles per day can be edited.
All work steps are made up of 3 T-steps. The first T-step of a work step is the total duration of
the work step. The two following T-steps specify the activation and deactivation periods within
this work step.
Example work step for aeration: T7 = 240 min is the total duration of aeration. Wíthin these 240
minutes, aeration alternates between ON for 6 min (T8) and OFF for 4 min (T9).
Functions
Feed
T 1 Σ
T 2 ON
T 3 OFF
Denitrification
T 4 Σ
T 5 OFF
T 6 ON
Aeration
T 7 Σ
T 8 ON
T 9 OFF
Sedimentation
T 10 Σ
T 11 ON
T 12 OFF
Clear water extraction
T 13 Σ
T 14 ON
T 15 OFF
Sludge return
T 16 Σ
T 17 ON
T 18 OFF
Cycle pause
T 19 OFF
T 20 ON
Holiday
T 21 ON
T 22 OFF
Cycle time
Aeration time
Total runtime
Cycles per day
Table 2: Layout of cycle tables
NOTE
When settings have been edited in the "Table selection" menu and the menu exited with the left
cursor key [◄], the message "Please wait ..." appears briefly. The edited settings are saved,
and the new table can then be viewed in the "T-settings" menu. A restart is not necessary.
8. Service menu for authorised specialist
Example values for 5 PE
SBR 2V
Flow class D
X31,
0.00 min
0.00 min
0.00 min
X31, X16.V1
90.00 min
18.00 min
1.00 min
X31, X16.V1
480.00 min
15.00 min
5.00 min
X31, -
120.00 min
0.00 min
120.00 min
X31, X16.V2
9.36 min
9.36 min
0.00 min
X31, -
0.00 min
0.00 min
0.00 min
X31, X16.V1
30.00 min
4.00 min
X31, X16.V1
4.00 min
30.00 min
699.36 min
12.13 h/d
12.44 h/d
2 1/d
X31, X16.V1
X31, X16.V2
X31, X16.V2
X31, -
X31, X16.V3
X31, X16.V4
X31, X16.V2
X31, X16.V2
62 / 137
Example values for 14 PE
SBR 4V
Discharge class C
13.11 min
13.11 min
0.00 min
0.00 min
0.00 min
0.00 min
232.70 min
10.00 min
10.00 min
90.00 min
0.00 min
90.00 min
13.11 min
13.11 min
0.00 min
1.00 min
1.00 min
0.00 min
15.00 min
2.00 min
2.00 min
15.00 min
349.93 min
8.00 h/d
9.81 h/d
4 1/d
