Intel NetStructure ZT 4901 Technical Specification page 38

Specifications
Table 10. J10 Board-to-Board Connector Pinout (Sheet 3 of 3)
38
Downloaded from Elcodis.com electronic components distributor
115 S2_INTR_EN
117 BMC_PWR_CTL
119 S2_BPRST-
121 LOC_INTD-
123 DASP
125 DA2
127 INTIRQ-
129 CS1-
131 CS3-
133 IORDY
135 DIOW-
137 DD15
139 DD14
141 DD13
143 DD12
145 DD11
147 DD10
149 DD9
151 DD8
153 SPARE_PAL2
155 SPARE_PAL1
157 SPARE_PAL3
159 SPARE
161 S2_ARB_EN-
163 MEZ_VIO
165 GND
167 SBC_RXP_B
169 SBC_RXN_B
171 GND
173 SBC_TXP_B
175 SBC_TXN_B
177 GND
179 SBC_RXP_A
181 SBC_RXN_A
183 GND
185 SBC_TXP_A
187 SBC_TXN_A
189 GND
TM
Intel® NetStructure ZT 4901 Mezzanine Expansion Card Technical Product Specification
116 S2_SYSEN_OUT-
D1 118 S2_RSS_LTCH
120 S2_ENUM-
GND 122 CSEL
124 PDIAG
D2 126 D_RSTDRV-
128 DA1
130 DA0
132 DACK-
D3 GND 134 DREQ-
136 DIOR-
138 DD0
140 DD1
D4 142 DD2
144 DD3
GND 146 DD4
148 DD5
D5 150 DD6
152 DD7
154 S2_TRNSFR_RQ
E1 156 S2_TRNSFR_NW
158 S2_MODELCK
GND 160 S2_BUS_Q
162 S2_ARB_LCKD
E2 164 S2_MODE_CH-
166 S2_BMC_XFR_RQ
168 NC_MEZZSPARE0
170 NC_MEZZSPARE1
E3 GND 172 NC_MEZZSPARE2
174 NC_MEZZSPARE3
176 NC_MEZZSPARE4
178 NC_MEZZSPARE5
E4 180 NC_MEZZSPARE6
182 NC_MEZZSPARE7
184 ISP_TCK
186 SBC_BYPASS_A-
E5 GND 188 IPMB_PWR3
190 SBC_BYPASS_B-
